- Even formation of the lint batt for the press.
- Optimizes pressing performance
- Made with superior technical know how
- Robust Construction
- Protects fibre quality
FEATURES & BENEFITS
- Even formation of the lint batt for the press.
- Drum peripheral speed could be varied to match Gin capacity.
- All rotating parts are provided with anti friction bearings for optimum efficiency.
- Easy to maintain; Low maintenance cost.
- High quality wooden rafters for doffing rollers adds to the life of roller.
- High density Nylon gears used for motion transmission reduces maintenance and optimize smooth functioning.
- Swinging arms provided to all 4 rollers reduce the thrust and allow better compression of all density lint.
TECHNICAL SPECIFICATIONS
| Capacity / hour (Avg) | 5000 kgs of lint | ||
 |
|||
| Power (Max) | 5 HP | ||
|
|||
| Height | 2100 mm | ||
|
|||
| Width | 2250 mm | ||
|
|||
| Length | 2180 mm | ||
|
|||
| Weight (approx) | 2000 kg | ||
|
|||
| Drum Diameter | 40” | ||
|
|||
| Optional Accessories | I) VFD drive for 5HP motor II) Panel for VFD |
||
